The INMOTION X1 is an electric unicycle built for high-performance and off-road riding. It is designed around power delivery, suspension performance, handling, and adaptability to demanding terrain, with a 235V full-charge high-voltage platform, a linkage suspension system, and a 2100Wh battery. This guide covers the X1's core specs, its performance boundaries, and everyday ownership notes in one place, so you can get to know the machine quickly.
Note: Real-world use is still subject to local regulations, road conditions, and safety requirements. Figures marked as design or reference values come with their applicable conditions; please refer to official controlled documents and the production version.
1. Basic Physical Specs
| Item | Value | Notes |
|---|---|---|
| Dimensions | 568 × 206 × 760 mm | Per X1 Core Specs V1.5 |
| Net weight | 41 kg | Without additional accessories |
| Max payload | 140 kg | Actual performance varies with rider weight, terrain, slope, and temperature |
| Tire | 2.75-14 off-road tubeless tire | 20-inch class wheel outer diameter, 14-inch rim |
| Factory tire pressure | 2.5 bar | Recommended baseline for checks |
The 206mm figure refers to the thickness of the wheel body, the part that sits between your legs while standing on the pedals. It directly affects how comfortably and securely your legs can grip the machine, making it a key ergonomic parameter of the X1.
2. Power and Riding Performance
Voltage Platform and Power Devices
Full-charge voltage is 235V.
For power electronics, the X1 uses SiC MOSFETs (silicon carbide), a solution suited to high-voltage power conversion that helps the high-voltage drivetrain meet its performance and thermal management goals.
Motor Power and Torque
- Rated motor power: 6kW
- Max motor power: 20kW (peak power is not continuous power)
- Max torque: 340N·m (test conditions per controlled reports)
Top Speed
Top speed is 75 MPH. Keep these boundaries in mind:
- This is a design figure and does not by itself prove a completed top-speed test on a production unit under the same conditions
- No-load speed is not quoted, and the design top speed should not be equated with a speed riders can safely use day to day
- Actual riding is always subject to software protection strategies and safety requirements
Max Climbing Angle
The X1's max climbing angle is 45°. Climbing capability depends on load, road grip, tire pressure, battery level, and riding style.
3. Suspension and Ergonomics
Linkage Suspension Structure
The X1 uses a linkage suspension structure made up of a shock absorber, linkage, pivot, and connecting hardware. In the standard mounting setup, wheel travel is 150mm.
Three Shock Mounting Configurations
| Configuration | Shock spec | Wheel travel | Notes |
|---|---|---|---|
| Standard mount | 205 × 60mm | 150mm | Default setup |
| Lowered mount | 205 × 60mm | 95mm | Lowers body height by 45mm |
| Long-shock mount | 225 × 75mm | 150mm | Travel unchanged |
Pedal Design
- Stepless angle adjustment, default angle 8°
- Three pedal height positions: 286mm, 304mm, 324mm
4. Battery, Range, and Charging
Battery Capacity and Cells
The X1 is currently presented with a 2100Wh battery. It uses EVE 50PL cells in a 56S1P × 2 pack configuration.
Discharge Capability
- Max continuous discharge current: 60A
- Max peak discharge current: 120A
Charging Specs and Charge Time
The X1 ships with a 16A charger rated at 235V DC output, and the wheel accepts a maximum charge current of 20A.
The current unified figure is: 16A charging, SOC 0-90%, about 35 minutes.
Charging Precautions
Use an INMOTION-approved charger. Keep the charging port dry and the environment well ventilated, and avoid overheating, water exposure, or unstable power sources. If you notice abnormal heat, smell, error messages, or damage, stop charging immediately and contact after-sales support.
5. Controls, Display, and Smart Features
Basic Controls
- Long press the power button: power on or off
- Short press the power button while on: toggle the headlight
- Double press the power button: enter or exit P mode / anti-spin mode
- Switch on the inside of the trolley handle: extend or retract the handle for everyday walk-assist
P mode is a parking and carrying assist under specified conditions; it is not a braking function while riding.
Display
The display shows: real-time speed, speed unit, battery bars, battery percentage, riding mode, Bluetooth status, lock status, headlight status, and fault icons.
Lighting and Charging Port
- Headlight: 20W LED
- Daytime running light: yes
- Tail/brake light: 1W
- Fill lights: 3W×2
- Phone charging port: T
App and Riding Modes
Designed app features include: vehicle information, vehicle settings, OTA updates, ride tracking, community and sharing, Cloud Box eSIM, and related remote services. Riding modes currently include Comfort and Sport. Exact feature availability, regional availability, subscription terms, and the real differences between modes depend on the released app and final firmware version.
6. Safety, Protection, and Everyday Maintenance
Water Resistance
The design ingress protection ratings recorded in X1 Core Specs V1.5 are: IP56 for the wheel, IP67 for the battery pack, and IPX6 for the motor. These design figures should still be checked against the corresponding test reports and applicable configuration; an IP rating does not mean unlimited wading, extended riding in heavy rain, or pressure-washer cleaning.
Protection Functions and Temperature Range
The X1 includes battery and system protection design covering voltage, current, temperature, and related fault protection. Exact trigger strategies and protection logic depend on the production hardware and software version.
- Operating temperature: -10 to 45℃
- Storage temperature: -20 to 45℃
Pre-Ride Checks and Troubleshooting
Before every ride, check tire pressure, battery level, display warnings, tires, pedals, suspension, and external fasteners, and always wear a helmet and the necessary protective gear.
Safety reminder: If you experience abnormal alarms, unexpected power cutoffs, a serious crash, water ingress, unusual noises, or abnormal heat, stop riding immediately and contact authorized after-sales or technical support. Do not keep riding on a compromised wheel.
Wrapping Up
The X1's core identity comes down to this: a 235V full-charge high-voltage platform, linkage suspension with 150mm of wheel travel in the standard setup, a 2100Wh battery, and pedals with three height positions and stepless angle adjustment. It is aimed at riders chasing high performance and off-road capability; if light commuting matters more to you, it is worth comparing other INMOTION models before deciding.
